Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 1401

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery, 1922, leaf 1401
p A limits the current which canflow through B and C^ and that current which does flowdivides between B and C in proportion to their conductivi-ties. If B has a resistance of 110 ohms and C 220 ohms,then B will carry two parts of the current and, C only one.The combined resistance of all lamps.… … Fig. eSO ance of B and divided by the sum of all the resistances. Ifthe resistance of each of the lamps were 110 ohms, theproblem would work out thus: 110+110X110 110+110+110 ^^ ^Z^-In Fig. 650 the total resistance is 110X220 hll0=183 1/3. 110+220 One practical illustration of the above law may be…
