Small, Sidney Aylmer, 1876- [from old catalog] · Chicago, F. J. Drake & co · leaf 364
direct current motor running on the incomingvoltages. On the same armature core is a separate wind-ing connected to its own commutator at the other end ofarmature. The one set of field magnets serves for themotor winding and the generator or dynamo winding. 364 ROTARY CONVERTERS. As the sub-station… … _ Fig. 169. Typical Rotary Converter Switchboard. the functions performed by the two machines describedabove. Thus in one sense it may be regarded as an alter-nating-current synchronous motor, driving a direct-cur-rent generator, or if the machine be inverted, it may beconsidered a direct-current…
Electricity
