Small, Sidney Aylmer, 1876- [from old catalog] · Chicago, F. J. Drake & co · leaf 64
ne is described bySilvanus Thompson. Before describing some special forms we will deal witha generalized type of machine having two fixed field- ELECTRICAL MACHINES 65 plates, A and B, which are to become respectively + and—, and a set of carriers, attached to a rotating disk orarmature. Figure 21… … Pig. 21. Diagram to show the principles upon which the ToeplerMachine operates. the six carriers p, q, r, s, t, and u being attached to theinside of an inner rotating cylinder. The essential partsthen are as follows: (I) A pair of field-plates A and B.(II) A set of rotating carriers p, q, r, s, t,…
Electricity
