Elementary lectures on electric discharges, waves and impulses, and other transients (1914)
Steinmetz, Charles Proteus, 1865-1923 · New York, London, McGraw-Hill book co., inc. · leaf 131
Traiisuiission Line 500 Step upTransformer u = ioo Transmission LineU = 500 Load u … Fig. 55. U„= 533 Energy Distribution in Compound Oscillation of Closed Circuit;Low Line Loss. In a closed circuit, as here discussed, the relative intensity ofthe two component waves of opposite direction is not definite,but depends on the circuit condition at the starting moment ofthe transient.…
Electricity · Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
