Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship (1893)

Langmaid, Joseph, Gaisford, H · London, New York : Macmillan · leaf 67

An illustration from Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship, 1893, leaf 67 — I ; 1 ! 1 Fig. 22.—Construction ofWhitworth Thread. (Page 44.) … Fig. 23.—Method of Showing Rough Sketch of Screw Thread. (Page 55.) 47

Steam-engines · Marine engines
