ach. Theneutralizing brushes nv n2 are small whispa of finespringy brass wire, and are mounted on the ends of adiagonal conductor Z. The appropriating brushes <7r a2are also of thin brass wire, and are fastened to clampsprojecting from the edge of the fixed disk, so that theycommunicate… … BACK FIXED DISK WITHFIELD PLATES ON BACK. FRONT ROTATING DISKWITH CARRIERS ON FRONT. Fig. 37. Dr D2. These also communicate with two small Leydenjars Jv J2, the function of which is to accumulate thecharges before any discharge takes place. These jars areseparately depicted in Fig. 38. Without…
