Elementary linear perspective of form and shadow ... Complete in itself ... For draftsmen, artists, and industrial drawing courses in preparatory and high schools, etc. In two parts.. (1891)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 107
ars, let C bethe centre of the picture (113) and D the vanishing point of diago-nals. C is the vanishing point of perpendiculars (112) and theseperpendiculars, as LK, AH, etc., pierce the perspective plane at K,H, etc., hence (116) KC, HC, etc., are their perspectives. AB if? MISCELLANEOUS… … i—V
Perspective · Mechanical drawing
