efraction. There-fore, the prisms used in instruments in nearly all cases are of the type inwhich a reflecting surface is used to produce the deviation. Figure 16shows such a prism. The ray indicated by the full line falls upon thefirst face perpendicularly and proceeds as a single ray without… … M ling prism. 22 without being divided into its different colors. Tlie case is somewhatdifferent for a ray falling upon the first surface obliquely. The rayshown by the dotted line incident at J is refracted and we shouldexpect to find the final image colored. The ray, however, is again
