Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .. (1880)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 208
SUPPOKTEES AKD CEAKK MOTIONS. 125 rim cd consists essentially of two thin plates enclosing a hollowinterior of width, 3f, shown on the fragment of end elevation—the scale is -f%, as in Ex. 5. The shaft opening, of centre 0, is 6 in diameter, surroundedby solid metal 1 thick as indicated. The arm OQ…
Geometrical drawing · Mechanical drawing
