Elementary treatise on electricity and magnetism : founded on Joubert's "Traité élémentaire d'électricité" (1909)
Foster, G. Carey (George Carey), Porter, Alfred William, 1863-1939, Joubert, Jules François · London : Longmans · leaf 189
Fig. 101. 16G GALVANIC OR VOLTAIC BATTERY [109 In all the cells mentioned the dnc terminal is negative. Fig, 102 represents the mode of connecting a number of cells … f^^^^r- FiG. 102. to form a battery, and shows a conducting wire joined to oppositeterminals of the first and last cells. CHAPTER XI ELECTRIC CURRENTS—RESISTANCE—OHMS LAW 110. The Electric Current.—We have already said (105) thatwhen the terminals of a battery are connected with the plates ofa…
