potential, thermo-electricpiles produce only feeble chemical actions. Botto, however, with 120 platinumand iron wires, decomposed water. 948. Thermo-electric diag-ram.—Thermo-electric relations may be veryconveniently illustrated by means of what is called the thermo-electric dia-gram. In fig. 944… … laUuc, the corrcsixjnding differences of potential arc reprcscntcil by anordinate according to a definite scale. In the diagram the ordinates repre-sent microvolts (964), and lead is taken as standard. A line which connectsthe ordinates thus determined is called a thermo-ctectric tine ; the lines…
