Niaudet, Alfred, 1835-1883. [from old catalog], Fishback, L. M., [from old catalog] tr · New York, J. Wiley & sons · leaf 33
zinc were so arranged that,being connected at the top, the plate of zinc was placedin one cup and the plate of copper in the next. This battery is truly the model of all those existing 14 SINGLE-LIQUID BATTERIES. to-day, and will be our model for reference in the descrip-tion of others. It is… … Fig. 4. CKUIKSHAlSrKS BATTEKY. Tins battery is composed of a wooden trough, inter-nally coated with marine glue and divided into cellsseparated by metallic partitions ; these partitions arecomposed of two thin plates, one of zinc and the otherof copper, soldered together. They are arranged in sucha…
Electric batteries
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
