Elementary treatise on physics, experimental and applied : for the use of colleges and schools (1906)

Ganot, A. (Adolphe), 1804-1887, Atkinson, Edmund, 1831-1901, Reinold, A. W. (Arnold William), 1843-1921 · New York : Wood · leaf 64

An illustration from Elementary treatise on physics, experimental and applied : for the use of colleges and schools, 1906, leaf 64 — , by various me-chanical contrivances obtain very closeapproximations to the theoretical figures.Tisleys Compound Pendulum apparatusor Harmonograph is one of the best ofthese. It consists of two pendulums (fig. 43)with adjustable sliding weights vibratingabout knife edges in planes at right… … tig- 44 pendulums are vibrating the pencil point traces a curve which is the result ofcompounding the curves produced by the separate vibrations. The relative -59] Compositioji of Simple Harmonic with Unijorm Motion 47 periods are varied by altering the positions of the sliding weights.…

Physics

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
