e againstthe left-hand stop, as shown in Fig. 64; draw a line alongthe slope side; hold the triangle stationary with the fingers ofthe left hand, and with the thumb move the strip to the leftuntil it is stopped by the triangle. Next hold the strip sta-tionary and slide the triangle until it comes… … MECHANICAL DRAWING AND DRAFTING ROOM PRACTICE 83 at the edges only, as this saves time and usually gives a betterappearance; in such cases the distance between the section lineswould be increased somewhat. Sectional views may be drawn in any suitable position onthe drawing, but it is always best to…
