Foster, Edwin W. [from old catalog] · Garden City, N.Y., Doubleday, Page & company · leaf 42
very important subject to young woodworkers,it will be given in füll in the next chapter. III MECHANICAL DRAWING IN TAKING up mechanical drawing, saidRalph, always remember that accurate andneat work, containing all necessary dimensions,is half the battle. You will probably f eel, as I did atfirst,… … Fig. 17. The outfit for mechanical drawing sions. This saves much time at the wood pile, andteils at a glance to just what size you must Squareup each piece of stock. 23 24 CARPENTRY AND WOODWORK The drawing boardisan absolute necessity. Itneed not be perfectly Square, but the surface mustbe flat…
Carpentry · Woodwork
