Fig. 81. — Layout of Drawing C-ioi. the complete detail drawings of these parts, drawn to a reducedscale, and their location on the sheet is shown in Fig. 81. Asit is essential to be able to arrange the views of a drawingsymmetrically on the sheet, this is the only drawing in whichthe arrangement… … MECHANICAL DRAWING AND DRAFTING ROOM PRACTICE 119 which the bill of material and title has been made out. (SeeFig. 83.) These features should therefore be noted carefully. Before starting on Drawing C-ioi read, and prepare for exam-ination, subjects taken up in paragraphs as follows: Introductory,…
