Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 252
sual marks on all finished sur-faces. Surely the shopman will have little trouble in building thiscommutator from the drawing, with its wealth of detail information.How many dimensions could be omitted and how many lines leftout and still be sure of the information being complete? Justenough is… … 238 MACHINE DRAWING PLATE Q. ARMATURE SHAFT Details and Dimensions. The revolving parts have nowbeen completed with the exception of the shaft. From the previousdrawings all data is available for making the shaft drawing as shownin Plate G. The center lines of bearings, the center line of…
