Blessing, George F. (George Frederick), 1875-1921, Darling, Lewis A. (Lewis Andrew) · New York, J. Wiley & sons; [etc., etc.] · leaf 163
one anothermust be carefully studied, and the sketch not merely copied.. Before starting this work read, and be prepared for examina-tion on, paragraphs, as follows: Cross-section Paper, page 5, §4.—Erasing Shield, page 17,§ 16.—Projection and Projected Views, page 73, § 53.—Num- 142 ELEMENTS OF… … Fig. 98. — Perspective of Main Casting of Headstock. Determine the location and purpose of the Headstock. SeeFrontispiece. Specific Instructions, (a) Fasten the sheet On the small draw-ing board. (See page 2, § 2.) (b) Stamp in and fill out title-form. (Seepage 138, § 98.) The title of this sketch…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
