Blessing, George F. (George Frederick), 1875-1921, Darling, Lewis A. (Lewis Andrew) · New York, J. Wiley & sons; [etc., etc.] · leaf 184
Fig. 129. —Isometric Drawings of Cylinder in DiflEerentPositions. … Fig. 130 Nut and Bolt with ConventionalIsometric Thread. shown in Fig. 130. To make such a drawing consider the bodyof the bolt as a cylinder and proceed as in § 125, this page. Theellipse which represents the base of the cylinder is to he repeatedin the proper positions to indicate the threads,…
Mechanical drawing
