Elements of drawing (1912)

Blessing, George F. (George Frederick), 1875-1921, Darling, Lewis A. (Lewis Andrew) · New York, J. Wiley & sons; [etc., etc.] · leaf 73

An illustration from Elements of drawing, 1912, leaf 73
tends up one-third the height of j_letter. |f4 is horizontal and extends one-third across the letter. h ^ ^ Capital D. 3 strokes, fti is standard slope. The right-hand half of the letter J^is practically the same as the right -^- half of O. (See page 51.) The D is slightly narrower than the 0.…

Mechanical drawing
