Elements of mechanism: elucidating the scientific principles of the practical construction of machines, for the use of schools, and students in mechanical engineering, with numerous specimens of modern machines, remarkable for their utility and ingenuity (1852)

Baker, T. (Thomas), d. 1871 · London, J. Weale · leaf 79

An illustration from Elements of mechanism: elucidating the scientific principles of the practical construction of machines, for the use of schools, and students in mechanical engineering, with numerous specimens of modern machines, remarkable for their utility and ingenuity, 1852, leaf 79
y velocity that the case may require. Note. It is usual in practice to make the two groups of speed pulleys, Art. 87, exactly alike, as well as the alternate cones, Art. 88, placing the small end of one set opposite to the large end of the other. THE EACE-WHEEL AND ROLLER. 89. The face wheel and… … distances from the axis of the face- wheel. The roller c, with its axis, will therefore receive from a b a rotation by rolling contact, which may be varied to suit the required purpose. Tor further information on this subject, see Prof. Willis's Mechanism , Art. 480 ; and Buchanan on Machinery ,…

Mechanics · Machinery, Kinematics of · Machine-tools

Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
