ale. From h we draw a line parallel to BE and we find itintersects ad at d. This shows that d and e are one and thesame point, and that there is no stress in the vertical post DE.The purpose of DE is to prevent sagging in the horizontalmember. As a further illustration we will consider the… … STRESSESEF = 6,9HG= 3.0 V TiesIE = 8.7JAF = 8.0BG^e.O GF=2.0> strutsCH = 6.0Dl =10.0IH=4,0. Fig. 99 156 THE ELEMENTS OF MECHANICS OF MATERIALS the left support and, with a scale 0.25 inch to the ton, obtain eafas the triangle of forces for the joint. Marking with arrowheadsthe kinds of stresses…
