t of the angle BOB. In the table of secants we findopposite 21° 48 the decimal 1.077, which, multiplied by theradius 3% = 4.0387, or say 4.039 for the length O B, asshown. Now as A C is always at right angles to B O, then wehave a right angled triangle A O B, figures 12 and 13. In thelatter figure… … THE MACHINIST AND TOOL MAKERS INSTRUCTOR. 141 below the pitch line, forming two separate right angled trian-gles : the one above the pitch line for finding the angle to turnthe pinion, and the one below the pitch line for finding theangle to cut the teeth. As A C is 90° from O B and the length is…
