Elements of mechanical drawing (1893)

Sullivan, Christine [Gordon]. [from old catalog] · New York, Cincinnati [etc.] American book company · leaf 46

An illustration from Elements of mechanical drawing, 1893, leaf 46 — Fig. 65. … Fig. 66. Fig. 67. Exercise 5. —Draw a sphere having diameter of 6 feet (Fig. 67) ; also plan and elevation (Fig. 66). 42 ELEMENTS OF MECHANICAL DRAWING.
