Jamison, Alpha Pierce. [from old catalog] · New York, J. Wiley & sons; · leaf 177
ne. (Reference, Sect. 76.) Draw the figures in the order numbered, using the followingdimensions: ^ = ij, J3 = iJ, C (the distance of the center linefrom the left border) = 2§; ground line to be in center of sheet.Omit all dimensions. 180. Sheet No. 23.—Execute a full-sized, well-balanced draw-ing…
Mechanical drawing
