Elements of mechanical drawing (1911)

Jamison, Alpha Pierce. [from old catalog] · New York, J. Wiley & sons; · leaf 51

An illustration from Elements of mechanical drawing, 1911, leaf 51 — xtend below them. Theletters C, G, O, and Q may be made slightly elliptical in shape,having a greater width than the side of the square. The letterY may be given increased width across the top. The letters M and N are also susceptible to modification,though not for the same reason given above. To… … LETTERS, FIGURES AND LETTERING. 33 PLATE No. 3.
