u_ PROJECTION. 69 To Develop the Cylinder.—Drawings 1 and 4, Fig. 5, show anend and side view of the cylinder, respectively, the elements showingin their true lengths in the side view; to develop the cylinder,draw the vertical line L-L, Fig. 2, and draw the two indefinitehorizontal lines L-L. Now,…
