inclined plane and the wheel and axle. Thescrew thread is simply an inclined plane wrapped around acylindrical support. The pitch of the screw—that is, the ver-tical distance be-tween two neigh-boring threads—isthe height of theplane. The threadcorresponding toone complete turnis the slant lengthof… … Fig. 42.—Screw. 84 PHYSICS screw by means of the principle of virtual velocities. Thusthe force, p, moves through the circumference of a circle,whose radius, r, is the radius of the wheel, while the weight,wy advances a distance equal to the pitch of the screw. ws = pd.iv X pitch = p X 2 irr. ~…
