Elements of plane and solid free-hand geometrical drawing, with lettering; and some elements of geometrical ornamental design, including the principals of harmonic angular ratios, etc. In three parts ... for draughtsmen and artisans; and teachers and students of industrial and mechanical drawing (1878)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 150
e the angles at a and h with any simple ratioto each other. In the figure, this ratio is \, the angles at a and5 being respectively of 30° and 60°. So much being done, mark the points b, C, a on the edge ofa slip of paper, and then adjust the position of the slip by trial. 114 FREE-HAND GEOMETRICAL… … Then, assuming any points, as n and ^, equidistant from C forconvenience, draw n m and^ r perpendicular to A B ; and drawO n and O^, and note their intersections, n^ and j?i with a^ h^.Also note c,. Finally, at n^ c^, J9, draw perpendiculars to a^ b^,and make n^)n^ = nm; c^Oj = CO ; p^ r^=^jpr.…
Geometrical drawing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
