Elements of plane and solid free-hand geometrical drawing, with lettering; and some elements of geometrical ornamental design, including the principals of harmonic angular ratios, etc. In three parts ... for draughtsmen and artisans; and teachers and students of industrial and mechanical drawing (1878)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 174
GEOMETRICAL DRAWING. trates one or more of these variations. Similar points havingthe same letters on all of them, and the construction of allbeing the same, with one exception, next mentioned, repeateddescription is unnecessary. But note, that when the angle A O B is divided unequally,as in Figs.… … 445: en ,.-■; «mj .Returning to the illustrations ; In Fig. 23, a S h is a rightangle, while in Fig. 24, it is not. In Fig. 22, A O B is dividedequally, and in Figs. 23, 24, etc., it is not; the degrees in eachdivision being marked at D. In Fig. 23, the angles at a and b CURVILINEAR GEOMETRIC…
Geometrical drawing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
