Ex. 75. A rightangled trianglewith equal acuteeach. angles of 45c This triangle possesses the property of being divided by a per-pendicular from its right angle to its opposite side, into twotriangles of the same shape as the original whole. This prop-erty makes its construction easy. Draw this… … Ex. 76. A triangle each of whose halves is a right angled PLANE FIGURES BOUNDED BY STRAIGHT LINES. 21) triangle with acute angles of 36° and 54°. Here ||o=|; $ j:=|and $$o=f. Also in the whole triangle ■3£^,=$. These ratiosbeing varied, while all of them are simple, the triangle is verypleasing and…
