An encyclopædia of cottage, farm, and villa architecture and furniture : containing numerous designs for dwellings from the cottage to the villa including farm houses, farmeries, and other agricultural buildings, several designs for country inns, public houses, and parochial schools, with the requisite fittings-up fixtures and furniture ; and appropriate offices, gardens and garden scenery ; each design accompanied by analytical and critical marks illustrative of the principles of archtiectural science and taste on whihc it is composed (1836)
Loudon, J. C. (John Claudius), 1783-1843 · London : Longman, Rees, Orme, Brown, Green, & Longmans, and sold by John Weale, at the Architectural Library, High Holborn · leaf 276
platesare let into the sleepers in the manner shown by fig. 447 (to a scale of three eighths of aninch to an inch). In this figure, / is the sleeper ; 9, the bottom plate; h, the corner postlet into it, in which is fixed a screw-nut, for being taken hold of by a screw-bolt that passesthrough the… … three inches on the sides. There are seven intermediate posts, and three posts in thepartition, each of which is three inches and a half on one side, and two inches and aquarter on the other. There are five joists, each five inches by two inches, which arejoggled on to the sleepers and to the…
Architecture, Domestic · Furniture
