An encyclopædia of cottage, farm, and villa architecture and furniture : containing numerous designs for dwellings from the cottage to the villa including farm houses, farmeries, and other agricultural buildings, several designs for country inns, public houses, and parochial schools, with the requisite fittings-up fixtures and furniture ; and appropriate offices, gardens and garden scenery ; each design accompanied by analytical and critical marks illustrative of the principles of archtiectural science and taste on whihc it is composed (1836)
Loudon, J. C. (John Claudius), 1783-1843 · London : Longman, Rees, Orme, Brown, Green, & Longmans, and sold by John Weale, at the Architectural Library, High Holborn · leaf 446
; the rafter, o ; and the eaves board, p. The scale of this figure is twoinches to a foot. Fig. 865 is a view of part of the barge board, and the gable post; in which are shownthe sunk panel, q, of the pinnacle; the gable post, r ; the pierced openings in the vergeboard, s s; the raised ornaments… … Fig. 866 is the front view of the entrance porch, and Fig. 867 is the side view of the same porch ; both are drawn to a scale of six feet toan inch. Fig. 868 is a cross section of the oak coping of the wall of the porch. Fig. 869 is a view and sections of the bracket part of the post, and part of…
Architecture, Domestic · Furniture
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
