An encyclopædia of cottage, farm, and villa architecture and furniture : containing numerous designs for dwellings from the cottage to the villa including farm houses, farmeries, and other agricultural buildings, several designs for country inns, public houses, and parochial schools, with the requisite fittings-up fixtures and furniture ; and appropriate offices, gardens and garden scenery ; each design accompanied by analytical and critical marks illustrative of the principles of archtiectural science and taste on whihc it is composed (1836)

Loudon, J. C. (John Claudius), 1783-1843 · London : Longman, Rees, Orme, Brown, Green, & Longmans, and sold by John Weale, at the Architectural Library, High Holborn · leaf 736

An illustration from An encyclopædia of cottage, farm, and villa architecture and furniture : containing numerous designs for dwellings from the cottage to the villa including farm houses, farmeries, and other agricultural buildings, several designs for country inns, public houses, and parochial schools, with the requisite fittings-up fixtures and furniture ; and appropriate offices, gardens and garden scenery ; each design accompanied by analytical and critical marks illustrative of the principles of archtiectural science and taste on whihc it is composed, 1836, leaf 736 — eheight of this mass of brickwork, a b, measured from the floor or pavement of the kitchen,is just three feet. Fig. 1356 shows a horizontal section of the mass of brickwork, in which the boilers,&c., are set, taken at the level of the horizontal flues that carry off the smoke from theboilers,… … by separate flues to a circular cavity, over which a large shallow boiler is placed; inwhich water is heated (by this smoke) for the use of the kitchen, and more especially forwashing the plates and dishes. (This boUer is distinctly seen, with its wooden coverconsisting of three pieces of deal,…

Architecture, Domestic · Furniture

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
