The Coxe stoTcer consists of a travelling grate Avitli fire on its upper surface. Thecoal is fed by the motion of the grate at the front. There are four blast compartments,A, B, C, D, under the fire connected by dampers. The sides of the furnace are pro-tected by wrought-iron water backs, through… … The Stirling Boiler consists of three upper steam-drums and a lower mud-drum. Allthe steam-drums are connected at the top, but the front and middle drums only are con-nected in the water space. Tubes, 3^ diameter; movement of flame shown by arrowsaround baffle plates. 868 SCRAPS.
