The engineer's sketch-book of mechanical movements, devices, appliances, contrivances and details employed in the design and construction of machinery for every purpose; (1902)
Barber, Thomas Walter. [from old catalog] · New York, Spon & Chamberlain · leaf 243
is reduced to a minimum. 1900. Is a variety of No. 1896, with tandem cylinders and two cranks for triple expansion. 1901. Is also a variety of No. 1898, with tandem cylinders for triple expansion. In this plan the intermediate stuffing box isgot rid of by using two piston rods to the lower… … 238 THE ENGINEERS SKETCH-BOOK. 1904. Horizontal twin screw engines. 1905. Plan of cylinders as usually employed for No. 1902. 1906. Oscillating paddle engines, sometimes made with cylinders at 90° apart and a single crank, as No. 564. 1907. Overhead oscillating twin screw engines. 1908. Annular…
Mechanical movements
