See Section 70. 2229. Bearing, with side brasses, sot up by a set screw. 2230. Ditto, with 3 brasses, set up by a set screw. 2231. Ditto, with 3 brasses, the side brasses set up by wedge bolts,regulated on top. 2232. Bearing, with 3 brasses, set up by side wedges and top screws. 2233. Schieles… … 286 THE ENGINEERS SKETCH-BOOK. Section 47.—PLATE WORK. ! {See also p. 106.) SHEET METAL JOINTS. 2234. Ring seam, with cover strip. 2235. Tolded ring seam. 2236. Half folded seam. 2237. Filleted ring seam. 2238. \2239.2240.2241.2242.2243.2244.2245.2246 & 2247. Intermediate seams, or diaphragms.…
