60®. 2300. Link hinges for reversing a door or shutter in opening or closing. 2301. Forked joint for pump rods, &c., with stepped gibs. 2302. Forked joint and swivel block for screw attachment. 2303. Swivel joint for pipe work. 2304. Door hinged to an intermediate square strip, so as to swing… … 294 THE ENGINEERS SKETCH-BOOK: 2307. Screw socket and spigot joint for rods. 2308. Conical socket joint and set screw. 2309. 2310, 2311 & 2312. Socket joints, various forms of. See also Section 28.2313. Taper drill socket. The drill socket end is shaped to fit a crossslot in the holder, into…
