The engineer's sketch-book of mechanical movements, devices, appliances, contrivances and details employed in the design and construction of machinery for every purpose; (1902)
Barber, Thomas Walter. [from old catalog] · New York, Spon & Chamberlain · leaf 35
aj_a_9_3_jLA … ^O THE ENGINEERS SKETCH-BOOK 182. Built crank. Several modifications of this are in use for large marine shafts. 183. Solid sheave eccentric. 184 & 185. Split sheave eccentrics. Large eccentrics cause great loss from friction, unless providedwitli friction rollers in the sheave; but are…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
