560. Overhead crank engine, cylinder oscillating. 561. Overhead cylinder engine, with oscillating cylinder. 562. Overhead tandem compound engine. 563. Overhead double compound engine. 564. Overhead one-crank compound oscillating engine, cylinders at right angles and receiver between. 565. Overhead… … 78 TEE ENGINEERS SKETCH-BOOK. 567. Vertical engine, with top guides, double connecting rods, andunderneath crank shaft. 508. Vertical trunk engine. Note that the trunk plan is applicable to any of the precedingarrangements, and is employed where a very short engine isrequired. 569. Vertical triple…
