The engineer's sketch-book of mechanical movements, devices, appliances, contrivances and details employed in the design and construction of machinery for every purpose; (1902)
Barber, Thomas Walter. [from old catalog] · New York, Spon & Chamberlain · leaf 87
or one cylinder may form a pump or blast cylinder. Insome designs the high and low pressure cylinders are placed sideby side and coupled to the same end of the beam by a modifiedparallel motion. 588. Side lever engine. 589. Plan of beam engine, with compound cylinders. 590. Walking beam engine.… … 586.
Mechanical movements
