The engineer's sketch-book of mechanical movements, devices, appliances, contrivances and details employed in the design and construction of machinery for every purpose; (1902)
Barber, Thomas Walter. [from old catalog] · New York, Spon & Chamberlain · leaf 87
586. … 82 TEE ENGINEEBS SKETCH-BOOK. Section 33.—ENGINES AND BOILERS COMBINED (seealso Boilers, Sec. 6). VERTICAL ARRANGEMENTS. 594. In this engine the boiler forms the standard for supportof engine parts, but it is better to fix these on a vertical bed-platebolted to the boiler, or as No. 595. 695. Any…
Mechanical movements
