ines. short vibrating rod, the upper end of whichis connected with the beam, and to the cen-ter of which the piston-rod is connected. \ 338. Another modification, in which theradius bar is placed above the beam. 339. Parallel motion for direct action en-gines. In this, the end of the bar, B, C,… … Mechanical Movements. 85 340. Another parallel motion. Beam, D, C,with joggling pillar-support, B, F, which vi-brates from the center, F. The piston-rodis connected at C. The radius-bar, E, A,produces the parallel motion. 341. Grasshopper beam engine. Thebeam is attached at one end to a…
