ined, the base circles are diawn tangent to the line of action, and the invo-lutes of those base circles will be the required curves. Care must be used in obtaining thelength of the teeth, in order to avoid a second engagement after the full action shall havetaken place. To determine if this… … Fig. 19 illustrates an annular gear of 20 teeth en-gaging a pinion of 10 teeth, the angle of pressurebeing 20°. The pinion driving in the direction indi-cated will establish the first i)oint of contact at A, andthe last point, B, ^^•ill be limited by the height of the tooth, in this case -. The…
