Beale, Oscar James, Brown & Sharpe Manufacturing Company (Providence, R.I.) · Providence, R.I. : Brown & Sharpe Mfg. Co. · leaf 40
other than the judgment of the de-signer, to effect the object to have spaces as wide aspracticable, just below or inside of base circle, andthen strengthen flank with as large a fillet as will clearaddenda of any gear. If flanks in any gear will clearaddenda of a rack, they will clear addenda of… … 22 BROWN & SHARPE MFG. CO. too much rounded at the points or at the addendumcircle. In gears of pitch coarser than 10 to inch (10AddTnJri of ■^) ^^^ having less than 30 teeth, this roundingTeeth. becomcs objectionablc. This rounding occurs, because in these gears arcs of circles depart too far…
Gearing
