re the effect of different fillets is indicated at B 94 ESSENTIALS OF DRAFTING in each of the views. In the first case there is an undercutting,in the second view B shows the irregular outhne produced, whilethe third case shows the correct design. Arcs and Straight Lines. — When arcs are used in… … F/g.s^o r/g. 2^/ rig. ^^f.3 Fig. 2^3 At A in Fig. 239 is shown the effect of not changing the radiuswhen two parallel lines are continued by arcs. At B the thick-ness of material has been kept by maintaining the same centerand changing the radius by the distance i. Flanged Projections. — When…
