Fig. ^93 … I- Oia. —j [— Dia. —^ fig. P9^ Be sure to pass planes through the contour or outside elementsof both cylinders in order to obtain the extreme limits of thecurve. This is very important, especially when the axes of thecylinders do not intersect. Choice of Cutting Planes. — Whenever possible planes…
