QUESTIONS, STUDIES, AND PROBLEMS 169 179. Space 1 x 11. Find the curve of intersection betweenthe two cyUnders, Fig. 424. 180. Space b^/2 X 1. Find the intersection between theprisms of Fig. 425. 181. Space 5V2 X 1. Find the intersection between thetwo prisms of Fig. 426. … BROHZC BOXES fC06C BOLT 182. Find the hne of intersection between the two cyHnders.(Fig. 294, first case.) Both diameters VU. Altitude 2V4.Axes intersect. 183. Same as Problem 182 but axes V2 apart. 184. Find the intersection between two cones (Fig. 294, secondcase). Diameters \^l% and altitude T…
