2912 pounds C. End rounded, V4 inch radius, 2573 pounds D. Cup shaped end, 2470 pounds The set screws were all ^/s inches in diameter, and were tightenedwith a pull of 75 pounds on a 12 inch wrench. Locking Devices. — The vibration of machinery often causesnuts to become loose if they are not…
