espe-cially suggestive plan, as it shows by arrows the cycle ofoperations in the preparing of food for the table, and thewashing and putting away of the dishes after the meal isfinished- The kitchen in the plan shown in Fig. 22 is onewhich allows for good light and air as Well as for… … 36 ESSENTIALS IN MECHANICAL DRAWING home conditions. The dimensions of kitchen furnishingson page 38 will be of assistance. Exercise ii. — (Home work.) Hand in a mechanicaldrawing showing side and end views of a table, bookcase,or dresser. Scale, iV = i\ If there is room, put in aborder line. Draw…
